Specifications
|
Part Number |
YX-240320T24N033A |
|
Size |
2.4 inch |
|
Resolution |
240xRGBx320 |
|
LCD Type |
IPS(Normally Black), Transmissive TFT |
|
Viewing Direction |
ALL |
|
Contrast Ratio |
800:1 (typ.) |
|
Outline Dimension |
42.72(W)x60.26(H)x2.2(T) mm |
|
Active Area |
36.72(W)x48.96(H) mm |
|
Dot pitch |
0.153(W)x0.153(H) mm |
|
Backlight LEDs |
4LEDs, 80mA |
|
Brightness |
400cd/m² (typ.) |
|
Lifetime |
50000Hours (typ.) |
|
Interface |
MCU/SPI RGB |
|
PIN Number |
50pins |
|
Operating Temperature |
-20℃~70℃ |
|
Storage Temperature |
-30℃~80℃ |
|
Touch Panel |
NO |
Outline Drawing:
